SMTAV PTZ Camera with USB3.0 HDMI Outputs,12X Optical Zoom,1080x1920 portrait mode,Built-in Mic,Live Streaming Camera
Main Features
●Portrait Mode
It supports output of 1080x1920 portrait video streams and can be streamed to major live streaming platforms.
●Full Function USB Interface
Full function USB interface, compatibility USB3.0 and USB2.0, support audio, support compressed video output, support UVC V1.1 protocol.
●1080P Full HD
Apply Panasonic's 1/2.8 inch, 2.07 million effective pixels high quality HD CMOS sensor, can reach maximum 1920 x 1080 high resolution and achieve quality image.
●Ultra-high Frame Rate
The output frame rate up to 60fps in 1080P.
●Low-light
High SNR of CMOS sensor combined with 2D and 3D noise reduction algorithm, effectively reduce the noise, even under low illumination conditions, picture can still keep clean and clear.The image signal-to-noise ratio is up to 55dB or more.
●12X Optical Zoom
Featuring a high-quality ultra wide-angle lens, it supports both 12x optical zoom and 16x digital zoom, capturing clear images from both near and far distances.
●Autofocus
Equipped with a built-in AF focusing algorithm and a TOF assistive focusing module, it enables the lens to quickly, accurately, and stably focus on the target.
Product Description
| Camera | |
| Video System | 1080P60，1080P50，1080P30，1080P25，720P60，720P50 |
| Sensor | 1/2.8'', CMOS, Effective Pixel: 2.07M |
| Scanning Mode | Progressive |
| Lens | 12x, f3.5mm ~ 42.3mm, F1.8 ~ F2.8 |
| Digital Zoom | 16x |
| Minimal Illumination | 0.5 Lux @ (F1.8, AGC ON) |
| Shutter | 1/30s ~ 1/10000s |
| White Balance | Auto,Indoor, Outdoor, One Push, Manual,VAR |
| Backlight Compensation | Support |
| Digital Noise Reduction | 2D&3D Digital Noise Reduction |
| Video S/N | ≥55dB |
| Horizontal Angle of View | 44.8° ~ 3.9° |
| Vertical Angle of View | 72.5° ~ 6.9° |
| Horizontal Rotation Range | ±170° |
| Vertical Rotation Range | -30° ~ +90° |
| Pan Speed Range | 1.61° ~ 75.56° /s |
| Tilt Speed Range | 0.44° ~ 15°/s |
| H & V Flip | Support |
| Image Freeze | Support |
| Number of Preset | 255 |
| Preset Accuracy | 0.1° |
| Built-in mic | Support |
| Mic Pickup Range | 6m |
| USB Featured | |
| Operate System | Windows 7, Windows 8, Windows 10, Mac OS X, Linux, Android |
| Color System / Compression | YUY2/ MJPEG |
| Video Format | YUY2 (ISOC): max to 1080P@60fps MJPEG: max to 1080P@60fps |
| Audio on USB | Support |
| USB Video Communication Protocol | UVC 1.1 |
| UVC PTZ | Support |
| Input/Output Interface | |
| USB interface | 1xUSB 3.0, Type-B |
| HD output | 1xHDMI1.4b |
| Audio Interface | 1xLine In, 3.5mm Audio Interface |
| Communication Interface | 1xRS232 In: 8pin Min DIN, Max Distance: 30m, Protocol: VISCA/Pelco-D/Pelco-P 1xRS485: 2pin Phoenix Port, Max Distance: 1200m, Protocol: VISCA/Pelco-D/Pelco-P |
| Power Jack | JEITA type (DC IN 12V) |
| Generic Specification | |
| Input Voltage | DC 12V |
| Current Consumption | 1A |
| Operating Temperature | -10°C ~ 40°C |
| Storage Temperature | -40°C ~ 60°C |
| Power Consumption | 12W（MAX） |
| MTBF | >30000 hours |
| Size | 118mm (W) × 129.2mm (D) × 157.3mm (H) |
| Net Weight | 0.9KG |
